Semi Automatic Long Seam Welding Machine , 2500W Resistance Seam Welder
| Brand Name: | XWH |
| Model Number: | XW |
| MOQ: | 1 |
| Price: | $4,000.00 - $7,000.00 |
| Packaging Details: | Wooden Case |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Detail Information
Place of Origin:
China
Certification:
CE
Product Name:
Semi Automatic 2500W Hot Air Internal Seam Welding Machine Cnc Rolling Circum Sealing
Welding Material:
Stainless Steel , Galvanized Steel , Iron
Rated Duty Cycle:
50%
Frequency:
50HZ/60HZ
Rated Capacity:
25KVA-400KVA
After Warranty Service::
Video Technical Support, Online Support, Spare Parts, Field Maint
Weight (KG):
800 KG
Welding Time:
0.1-1S
Supply Ability:
500 sets/month
Highlight:
2500W long seam welding machine
,semi automatic long seam welding machine
,2500W resistance seam welder
Product Description
Semi Automatic 2500W Hot Air Internal Seam Welding Machine Cnc Rolling Circum Sealing
| models Item | Rated power |
Voltage input | Frequency | Max short circuit current | Working stroke | Welding efficiency | Max force | Max welding capacity | Motor power |
| Unit | KVA | V | Hz | KA | MM | 0.7-3.9 | N | MM | W |
| FN-80-H | 80 | 380 | 50 | 26 | 100 | 0.7-3.9 | 6000 | 1.2+1.2 | 550 |
| FN-100-H | 100 | 380 | 50 | 30 | 100 | 0.7-3.9 | 6000 | 1.5+1.5 | 750 |
| FN-160-H | 160 | 380 | 50 | 40 | 100 | 0.7-3.9 | 7800 | 2.0+2.0 | 750 |
| FN-100-E | 100 | 380 | 50 | 30 | 100 | 0.7-3.9 | 6000 | 1.5+1.5 | 750 |
| FN-160-E | 160 | 380 | 50 | 40 | 100 | 0.7-3.9 | 7800 | 2.0+2.0 | 400 |
Features
The welding process is stable and easy to adjust
Internal cooling in welder, external cooling in welding wheel
High conductivity and rotation flexibility
Two welding modes: horizontal and vertical
Welding low carbon steel
Internal cooling in welder, external cooling in welding wheel
High conductivity and rotation flexibility
Two welding modes: horizontal and vertical
Welding low carbon steel
