Product Details:
|
| Product Name: | Saldatrice A Punti 220V Stainless Steel 12v 50 Kva Sheet Metal Foot Pedal Spot Welder | Frequency: | 50HZ/60HZ |
|---|---|---|---|
| Dimensions: | DN 10/16/25/35 | Welding Time: | 0.1-1S |
| Lead Time: | 3-5days | COLOR: | Customized |
| Machinery Test Repo: | Provided | Size: | 450mm |
| Highlight: | 450mm pedal operated spot welding machine,50Kva pedal operated spot welding machine,50Kva sheet metal spot welding machine |
||
| Models Item | DN-35 | DN-25 | DN-16 | DN-10 |
| Rated Power at 50% | 35KVA | 25KVA | 16KVA | 10KVA |
| Rated Primary Power | 380V | 380V | 380V | 380V |
| Rated Primary Current | 92A | 66A | 42.1A | 26.3A |
| Rated Duty Cycle | 10% | 10% | 10% | 10% |
| Secondary Unload Voltage | 2.6～4.2V | 2.3～3.55V | 1.98～3.01V | 1.65～2.4V |
| Adjustment Rated | 4 | 4 | 4 | 4 |
| Welding Time Adjustment | 0～9.99s | 0～9.99s | 0～9.99s | 0～9.99s |
| Arms Length | 280mm | 280mm | 280mm | 260mm |
| Max. Welding Capacity | 3.5+3.5mm | 2.5+2.5mm | 2+2mm | 1.5+1.5mm |
| Cooling Ways | Main Transformer: Air Electrode: Water | |||
Pedal Spot Welding Machine are used in car body producing, low carbon steel welding, Steel bar welding, Metal wire welding, Metal tube welding, also it can weld stainless steel, coated steel,security doors, cabinets. Meanwhile electrode arm can be custom-made according to your requirement.
